miniature modular

pressure sensors and transmitters

MP 3X series

MP 3X Series – Miniature modular pressure sensors and transmitters

Miniature Modular are miniature pressure transducers, threaded or flush mount

Key features:

2.5 – 3 mm diameter
Made of corrosive resistant titanium (6AL4V) or 17-4/15-5 PH steel– excellent performances with most corrosive and conductive media
Extended temperature range or high temperature options
Absolute or sealed reference options
Long term stability versions
High vibrations options
Configurable length, diameter, flush mount or threaded, and electronics housing

MP 30

Input 0-5V, DC or AC; Relative, Absolute or Sealed Reference

MECHANICAL

Standard Pressure Ranges: 2-500 bar

Non Standard Pressure Ranges: 1-700 bar

Other ranges possible contact us

PERFORMANCE

Balance (Zero): ±2 mV

Full Scale Sensitivity: 20±2 mV/V

Static Error Band: ± 0.25% F.S. (BFSL), max.

Long Term Stability: < 0.1% F.S. per year. (options)

ENVIRONMENTAL

Storage and Operating Temperature, standard: -20 °C to +80 °C

Extended Temperature Range: -54°C to +95 °C or 125 °C

High Temperature Version: -54°C to +250 °C

Acceleration: 100g any axis (high vibrations option)

Media Compatibility: Titanium 6AL4V or 17-4 PH steel

PTFE coated option

Other coating options (water, hydrocarbon, bio-fluid repellent, etc.)

ELECTRICAL

Input, constant Voltage Excited: 0–5 Volts DC or AC

Maximum Voltage (short periods): 30 V

view-download

Datasheet MP 30

MP 32

Input 4 mA, DC or AC; Relative, Absolute or Sealed Reference
